Section | Dimensions D X W | Web Thickness (BMT) | Web Thickness (TCT) | Full Sectional Area | Unit Weight | Moment of Inertia | Section Modulus | Torsion Constant | ||
(mm X mm) | (mm) | (mm) | (mm2) | (Kg/m) | Ixx(mm4) | Iyy(mm4) | Zxx(mm3) | Zyy(mm3) | J(mm4) | |
SC07515 | 75 x 40 | 0.75 | 0.80 | 122 | 0.99 | 112700 | 23860 | 2998 | 879 | 23 |
SC07520 | 75 x 40 | 1.00 | 1.05 | 159 | 1.31 | 143109 | 26467 | 3772 | 1017 | 53 |
DC07515 | 75 x 40 | 0.75 | 0.80 | 262 | 2.00 | 329049 | 65792 | 7246 | 3214 | 49 |
DC07520 | 75 x 40 | 1.00 | 1.05 | 345 | 2.63 | 424103 | 85623 | 9412 | 4192 | 115 |
SC10020 | 100 x 50 | 1.00 | 1.05 | 216 | 1.73 | 362000 | 71330 | 7100 | 2070 | 72 |
DC10020 | 100 x 50 | 1.00 | 1.05 | 459 | 3.47 | 970048 | 193537 | 16562 | 7446 | 153 |
TS61 | – | 1.00 | 1.05 | 195 | 1.56 | 99800 | 157000 | 3239 | 3083 | 65 |
TS40 | – | 1.00 | 1.05 | 154 | 1.20 | 74820 | 38360 | 2043 | 1811 | 25 |
Accurate dimensions and design flexibility provide clear span for accommodating more than sufficient.
Structural components are tailor made to provide modular approach; ensuring your vehicle is well protected from the harshness of the external environment.
EZYBUILD® Solutions come with high strength steel roof and wall cladding profiles; backed by THERMATECH® Technology ensuring high reflectivity with cooler comforts for peaceful working environments.
Ezybuild’s custom designs are most suitable for an architect’s vision, complementing the living spaces with the traveller’s lifestyle. With excellent weather ability; EZYBUILD® is your trusted partner for challenging weather conditions.
Our customised Purpose Built spaces suit your precise needs and the structures give a hassle free experience.
EZYBUILD®’s advanced, light-weight pre-engineered steel framing solution is apt for utility structures like grain storage, garages, machinery sheds, hangars and more.
EZYBUILD® is an advanced, light-weight pre-engineered steel framing solution; apt for smart structures like schools, institutions and colleges.
Accurate dimensions and design flexibility provides clear span for accommodating more than sufficient.
EZYBUILD® Solutions come with high strength steel roof and wall cladding profiles; backed with THERMATECH® Technology ensuring high reflectivity with cooler comforts for a peaceful meal.
Strength and rigidity allows for longer spans and wider spaces to suit your needs.
EZYBUILD® is easy and quick to install, enabling seamless spans for athletic facilities with different widths and heights.
Our customized purpose built structures give you hassle free experience.
S = Standard Inclusion, O = Optional Extra | |||
Features and Options | PEB-Lite® Solution | SMARTBUILD® System | SMARTRUSS® System |
Applications | Warehouse, Workshop Sheds, Mills, Dairy/ Agro Processing Units, Community Centres | Recreation Halls, Site Offices, Sample Flats, Roof/ Terrace Top Buildings, Farm Houses | Residential, Parking Sheds, Terrace Roofs, Institutions, Old Truss Replacements |
Building Dimensions Building Height: 6m Building Length: No Limit Clear Span-Width: 20m Multi Span-Width: 40m Bay Distance: 2.5 to 5m on case to case Extra Add on Bays: Existing bay distance | Building Dimensions Building Height: 3.2m Building Length: No Limit Clear Span-Width: 15m | Building Dimensions upto Building Length: No Limit Clear Span-Width: 15m | |
Heavy duty footing / anchor bolts | S | S | S |
Roof slope | S – 10 deg | As per requirement | As per requirement |
Gutter and Downpipe | O | O | O |
Steel Frame | Galvanised Portal | ZINCALUME® steel conti frame | ZINCALUME® steel gable/ hipped frame |
Main Frame Connection | Bolted | Screwed | Screwed |
C / Z section Purlin and Girts | S | – | – |
Top Span Purlin and Girts | – | S | S |
Trims and flashing | S | S | S |
Wall opening | As per requirement | As per requirement | – |
Fasteners | High grade – Class 3 type | High grade – Class 3 type | High grade – Class 3 type |
Footing plan | S | S | – |
Erection details | S | S | S |
Roof sheet | Bare/Color coated Zn-Al alloy coated steel | Bare/Color coated Zn-Al alloy coated steel | Bare/Color coated Zn-Al alloy coated steel |
Wall Sheeting | Partial / Full height | Full height | – |
Door and Window | O – ESP | O – ESP | – |
Fibre Glass Skylights | O | O | O |
Roof/ Wall Insulation | O | O | O |
Civil, Electrical, Plumbing | O – ESP | O – ESP | O – ESP |
Erection | ESP | ESP | ESP |
