Looks newer for longer
Launched in 1976, ZINCALUME® steel, the world’s leading Al-Zn alloy coated steel product is an outcome of extensive research and continues to set standards for corrosion resistance and long life. It is designed to withstand the rigors of various climatic conditions, and for over two decades, the product’s performance has been constantly monitored across a wide range of climatic conditions using exposure test sites and infield inspections.
ZINCALUME® steel
Cross SectionZINCALUME® steel has 150 g/m2 or 200 g/m2 metallic coating distributed equally on both surfaces. It is available in Base Metal Thickness (BMT) ranging between 0.30mm to 1.30mm and coil widths of 900 to 1250 mm. It is offered with yield strength of minimum 300 MPa to minimum 550 MPa depending on the application. ZINCALUME® steel complies with AS1397, ASTM A792M, IS 15961 and ISO 9364 standards
Durability
ZINCALUME® steel combines both the galvanic protection of Zinc and barrier protection of Aluminium. On an average ZINCALUME® steel (AZ150) lasts up to four times longer than Galvanised steel (Z275) in similar environmental conditions.
Higher Solar Reflectivity
ZINCALUME® steel has lower thermal mass as compared to conventional building materials, so it does not hold heat for long. The primary source of heat is sunlight. The fine spangle and special surface treatment of ZINCALUME® steel (with SRI value 57) enables it to reflect a greater portion of the sunlight and transmit less energy into the building.
Assured Performance
ZINCALUME® steel is manufactured using most advanced surface treatment technology, coated with special passivation and resin as a separate layer. This double layer protection ensures anti darkening property helping roof and wall cladding look newer for longer.
A surety of Genuineness
ZINCALUME® steel is supplied with a brand mark at regular intervals on the backer coat side of the strip. This assures highest quality, backed by a team of qualified, experienced personnel at Tata BlueScope Steel.
Environment Friendly
ZINCALUME® steel offers several environment friendly credentials. With no welding or wastage during construction; there is no damage to local flora and fauna. Steel is 100% recyclable – which means its life cycle is potentially continuous.
ZINCALUME® Applications
LGFS
ZINCALUME ® steel is a zinc/aluminium alloy coated steel with a distinctive clear resin surface finish, made by Tata BlueScope, specifically for Light Gauge Steel framing system market. Wall and roof frames made from ZINCALUME ® steel are termite and fire resistant, straight and true, light-weight yet strong.
Today, frames made from ZINCALUME ® steel are quick and simple to erect, easy on the environment, and adaptable to a myriad of building designs. Wall and roof framing made from ZINCALUME ® steel is 100% termite and borer proof. It is also non-combustible, which significantly reduces the amount of flammable material.
Wall and roof frames made from ZINCALUME ® steel are precision engineered to be dimensionally accurate so that it reduces the problems such as cracking cornices, jamming doors, sticking windows or wavy rooflines. Besides, it lends itself perfectly to innovative designs and non-conventional roof lines, helping to create distinctive, highly individualized buildings. In particular, the high strength-to-weight ratio of steel roof framing allows for longer spans, creating larger, more open living areas. And because it’s steel, it measures up against increasingly stringent building and fire regulations.
Pipe Cladding
The thermal insulation for piping, especially in the processing industry, plays a vital role. It is highly imperative to maintain the required temperatures of fluids or gases. In applications like hot or cold insulation (e.g. turbines, boilers, pressure vessels, chemical processes in refineries, pharma and metallurgical industries and critical cryogenic processes), a properly designed ‘Insulation System’ enables achieving targets set through energy conservation.
The Preferred Material
ZINCLAUME® steel is a preferred material for pipe cladding due to its excellent impact resistance, higher strength, flexibility and excellent corrosion-resistance. It is also an economical solution for certain applications. The 55 per cent aluminum-zinc alloy coating provides both, long-term corrosion resistance of aluminum along with the galvanic protection of zinc at scratches and cut edges. ZINCLAUME® steel jacketing has a substantially longer life when compared with regular galvanised steel in marine and industrial atmospheres. At the same time, it provides superior fire-resistance and protection compared to aluminum. The special alloy coating of aluminum and zinc combines the best properties of both metals.
Door & Window Frame
Superior Quality door / window frames can be made from ZINCALUME® steel and COLORBOND® steel. It provides immaculate strength along with excellent corrosion resistance without any warp or termite & thus improves life by several years.
Properties which make it an excellent preposition in this application are:
1. High Corrosion Resistance
2. Termite Proof
3. Guaranteed Material Strength (Dimensionally stable)
4. Low Wastage
5. Saves time & money during painting, as no primer required & can directly have top coat
6. Non Combustible
Rolling Shutter
The high strength and longevity of Tata BlueScope Steel provides the best value preposition for customers looking for an ideal solution for rolling shutters application. The features when clubbed with corrosion resistance and the aesthetic appeal becomes a more compelling value preposition for customers looking for a hassle-free long lasting solution.
Drywall Partition
The light weight of the drywall partition material combined with ease & simplicity of construction, makes drywall system a preferred solution in the Industry.
ZINCALUME® steel with it’s strength & lightweight becomes the first choice for steel stud frames which binds the gypsum / fiber cement boards. ZINCALUME® steel helps fabricate light gauge frames which in turn reduces the overall weight of partitions & drywalls and thus reduce the cost of installation and transportation.
ZINCALUME® steel with it’s strength & lightweight becomes the first choice for steel stud frames which binds the gypsum / fiber cement boards. ZINCALUME® steel helps fabricate light gauge frames which in turn reduces the overall weight of partitions & drywalls and thus reduce the cost of installation and transportation.
Solar power structure & water heater
Solar modules stand in very challenging environmental conditions for years & therefore the solar industry demands for high corrosion resistance material.
ZINCALUME ® steel satisfies the solar application requirement & plays a critical role towards increasing the life of the system. Due to Excellent weatherability,
ZINCALUME® steel gives an extra edge of up to 4 times life to critical parts of support system.
ZINCALUME ® steel satisfies the solar application requirement & plays a critical role towards increasing the life of the system. Due to Excellent weatherability,
ZINCALUME® steel gives an extra edge of up to 4 times life to critical parts of support system.
HR sections & reduce overall weight of structure which in turn reduces the transportation cost & makes installation easier. It inturn reduces the maintenance and replacement cost.
Roof and Wall
ZINCALUME® steel is one of the world’s leading Al-Zn alloy coated steel ideal for roofing, wall cladding and manufacturing alternate applications. Metallic coating of ZINCALUME® steel combines the corrosion protection of aluminium with sacrificial protection of zinc that enhances corrosion resistance and gives significantly longer service life than the galvanized coating. ZINCALUME® steel is manufactured using proven technology and durable surface treatment (coated with special passivation and resin as a separate layer) ensures your roof and wall cladding looks newer for a longer period of time.
Tools and Resources
Explore our comprehensive collection of ZINCALUME® product brochures, case studies and more.
ZINCALUME Steel for LGFSView Brochure
Multiple ApplicationView Brochure
ZINCALUME® 7 Good ReasonsView Brochure
ZINCALUME® Oustanding PerformanceView Brochure
ZINCALUME® G300 steelView Brochure
ZINCALUME® G340 steelView Brochure
ZINCALUME® G550 steelView Brochure
ZINCALUME® Steel, Mount Your Investments on Trust & QualityView Brochure
State of art manufacturing
Tata Steel founded India’s first industrial city, Jamshedpur, where it established India’s foremost integrated steel plant in 1907. View Case Study
Proven Performance
Steel Building are either made by conventional methods or by pre-engineered steel building method(modern technology). View Case Study
Longer LifeSpan
Pre-painted steel products offer increased corrosion resistance and enhanced aesthetics compared to bare metallic coated steel View Case Study
THERMATECHTM
COLORBOND® steel with THERMATECH™ Technology offers Cool Comfort than equivalent conventional roofing material View Case Study
Blend of Beauty with Durability
BASF, one of the world’s largest chemical producers, headquartered in Ludwigshafen, Germany decided to build a manufacturing unit in ChennaiView Case Study
Right Product Just for Your Needs
Mention COLORBOND® steel to India’s highly regarded architects & consultants, and they most commonly opine about the product being “highly prolific, flexible, durable and successful”. View Case Study
Environment Friendly Product
The main objective of a sustainable design is to reduce or completely avoid, depletion of critical resources like energy, water and raw materialsView Case Study
What is the difference between Base Metal Thickness (BMT) and Total Coated Thickness (TCT)?
The Base Metal Thickness (BMT) measures the steel substrate prior to any metallic coating or paint being added to the substrate. The Total Coated Thickness (TCT) measures the steel substrate as well as the metallic coating, resin coating and/ or paint film. If a Tata BlueScope Steel AZ150 coated product is labeled as 0.42mm BMT means that it will have TCT of 0.47mm. If the BMT is measured at 0.48mm means that the product will have a TCT of 0.53mm. For design calculations or structural design one should use BMT since the actual strength of the material is from its base steel. The metallic coating layer provides the corrosion resistance against natural weathering.
Does the thickness of the material affect the corrosion performance of my steel roof?
It is important to note that the thickness of the material has no effect on the products corrosion resistance. The type and amount of coating mass will affect the corrosion performance of the product.
What is SRI?
The Solar Reflectance Index (SRI) is a numerical expression of a constructed surface’s ability to reflect solar heat. SRI values are derived from a calculation in ASTM E1980 which uses a roof’s solar reflectance, thermal emittance and medium wind coefficient to generate a unit-less value from 0 to 100. A standard black (reflectance 0.05, emittance 0.90) is 0 and a standard white (reflectance 0.80, emittance 0.90) is 100.
The higher SRI values indicate a roof whose surface temperature is lower, thereby reducing heat gain in the living space beneath the roof. Green building rating tools such as Leadership in Energy and Environment Design (LEED) and Malaysia’s Green Building Index (GBI) encourage using building materials with high SRI values to reduce the intensity and impact of the Urban Heat Island (UHI) effect.
SRI Values required by LEED & GBI
Roof Slope SRI
Low-Slope _ 2/12 78 or greater
Steep-Slope > 2/12 29 or greater
What is Thermatech™ technology?
A solar reflectance technology is incorporated into COLORBOND™ steel to lower surface temperature by absorbing less heat from the sun. Thermatech™ optimizes the thermal performance of every colour in the standard COLORBOND™ steel palette, without changing their appearance. Thermatech™ provides greater thermal comfort (Cool Roof) all-year round, whilst using less energy for air-conditioning and helps to mitigate the urban heat island effect.
