BR-II™ 900

Deep Trapezoidal Roof and wall Cladding

LYSAGHT® BR-II™ 900 is a weather-tight deep trapezoidal roof and wall cladding system that is economical to install, maintain and is ideal for industrial and commercial applications. All BR-II™ 900 roof panels have a full 38.1 mm deep corrugation, thus making it the strongest fastened roof system in the industry.

Base Metal Thickness
0.42 mm/ 0.45 mm

Depth
38.1 mm

Overall width
965 mm

Steel
ZINCALUME ® steel, COLORBOND® XRW steel *Standard offering includes COLORBOND® XRW steel but other options like COLORBOND Ultra steel, COLORBOND® XPD steel and COLORBOND® Metallic steel can also be used after consultation from Tata BlueScope Steel authorities.

Steel Grade
G550 (550 MPa yield strength)

Total Coated Thickness
0.47 mm/ 0.50 mm

Effective cover width
900 mm

Min. Roof Slope
5 degree, 3 degree acceptable for applications without end laps and ridge

Coating Class (min.)
ZINCALUME AZ150 (150g/m2) (55% Aluminium, 43.5% Zinc, 1.5% Si) as per AS1397 / IS15961 – with Super Durable Polyester COLORBOND® steel XRW quality paint system of approved color conforming to AS/NZS 2728 type-4 / IS15965 class 3

Application
Roofing, Wall cladding

Deep corrugations for extra strength
BR-II™ 900 roof panel offers the deepest and a wide corrugation coupled with a high tensile steel base of minimum 550 MPa yield strength providing additional strength in comparison to any other industrial profile for both wind uplift and roof traffic

Additional support against roof traffic
To provide additional support against roof traffic, BR-II™ 900 roof panels incorporate a “return leg” on all side lap connections. Roof panels without return leg often separate under fastener installation or roof traffic

Leak proof performance
Anti-capillary groove for leak proof performance, which can also be used for sealant placement to ensure weather tightness
Pre Punched Profile (optional)
BR-II™ 900 roof system is also available in factory punched option to assure perfect alignment

Improved Thermal Performance
BR-II™ 900 profile comes with THERMATECH™ Solar Reflectance Technology that lowers surface temperature by absorbing lesser heat from the sun. It keeps both roofs & buildings cooler at reduced energy costs.

Surfmist

Headland

Pale Eucalypt

Cottage Green

Aquamarine

Sky Blue

Torres Blue

Bare ZincalumeTM

Note: Above standard colour shades are given for guidance only. The Colour shades may look different due to print limitation. Please contact the nearest Tata BlueScope Steel sales office for any other colour shade enquiry. We would be glad to send an actual COLORBOND® colour sample or help with any other colour requirement.
