SMARTDEK® 51 panel has a rib depth of 51 mm and provides an effective cover width of 960 mm. Embossments on top of the flange provide excellent mechanical interlocking between steel and concrete. In the assembled state, the profile comprises of intermediate male and female ribs for every interlocking side-lap joint.

Specifications
Effective cover Width | 960 mm | ||
Depth | 51 mm | ||
Base metal Thickness (mm) | 0.7 | 1 | 1.2 |
Steel Grade (Mpa) | 550 | 550 | 550 |
Zinc Coating (g/m2) | 275 | 275 | 275 |
Self weight (kg/m2) | 7.35 | 10.34 | 12.33 |
Full Cross Sectional Area (mm2/m) | 855 | 1222 | 1467 |
Inertia Moment Ix1 (mm4/m) | 381741 | 545345 | 654343 |
Section Modulus Zx1 (mm3/m) | 15765 | 22382 | 26755 |
Features
- Excellent spanning capacities for greater strength and less deflection
- Embossments provide mechanical interlock ensuring adequate composite action
- Precision engineered; brings greater economy and design freedom
- Ease of installation combined with safety
- Saves on concrete and reinforcement cost
- Greater corrosion resistance provides long life
